Light Duty Trailer Axles ManufacturerProfessional Light Duty Trailer Axles & Parts China Manufacturer

3500 lbs Torstion Trailer Axle Wholesale Manufacturer

3500 lbs Torstion Trailer Axle Wholesale Manufacturer
3500 lbs Torstion Trailer Axle Wholesale Manufacturer3500 lbs Torstion Trailer Axle Wholesale Manufacturer
CategoriesTorsion Trailer Axles
BrandHaway Trailer Parts Manufacturer
Model3500 lbs
Typetorsion axle
Capacity3500 lbs
Surface Finishblack painted
Brakewithout brake
Hubidler hub
bolt pattern5 on 4.5''
FOB portQingdao
Terms of PaymentL/C, D/P, Western Union, T/T, Paypal
Download DOCpdf icondoc iconxls icon
Update TimeNovember 29,2022
Detail Information

3500 lbs Torstion Trailer Axle Wholesale Manufacturer


● Weight capacity: 3500 lbs

● Axle beam size: 65 x 65mm square tube

● Axle length: custom length

● Spindle: φ45mm spindle

● Mounting bracket type: customized

● Starting angle: 23 degree down or customized

● Hub: idler hub

● Bolt pattern: 5 bolts on 4.5''

● Surface finish: black painted

● Brake: no brake

● Brake mounting flange: optional

● Inner bearing: L68149/11

● Outer bearing: L44649/10

● Dust cam diameter: 50.3mm

● Grease nipple: option

3500 lbs Trailer Torsion Axle Kit features

● Torsion Axle is a kind of independent suspension which attached to trailer frame directly and no leaf spring needed.

● Torsion axle provide suspension characters through the steel torsion bar and the rubber cords in the axle beam.

● 3500lb torsion axle no brake is fitted with casting idler hub.

● There are grease nipple on the spindle for ease lubing bearing.

● Although the no brake fitted the brake mounting flange are welded on. So the idle hub can be changed to brake drum when needed.

● The easy installation brackets can be supplied in various kinds and sizes.

Contact us to get quotation now.

We are a torsion axle manufactuer in China. Most of our axles are sold to north America and Australia markets. They are suit for these market standard and you can find the replaced components locally. We do wholesale only Products MOQ is 10pcs. But one or several samples can be supplied.

Frequently Asked Questions And Answers about 3500 lb Trailer Torsion Axle Kit

● Do you supply 3500 lbs torsion axle with brakes?

   Yes, we supply 3500 lbs with electric brakes and hydraulic brakes. 3500 lbs with electric brakes are the hot sales model.

● What is your torsion axle hub face length?

   We can make any hub face length rubber torsion trailer axle as your rerquirement.

● Do you have any stock for 3500# torsion trailer axle?

   We are the torsion trailer axle manufacturer and produce based on customer's order quantity. Usually there is no stock.

● How many 3500 lb trailer torsion axle can be fitted in a 20ft container?

  Loading quantity is affacted by axle length. Only the length is decided I we can tell you loading quantity per container.

● Do you do custom axle?


  Yes, we can make trailer axles as your requirement.
